ALUMINUM BOAT LIFT

12,000 LBS Capacity

  • Free-standing hydraulic lift re-charged with solar power
  • Touch-of-a-button seamless launch
  • Custom styled aluminum extrusions
  • A hull’s best protection: Super Cush™ Rubber Bunks
  • Dual Stainless Steel Cylinders
  • 53″ & 65″ Lifting ranges



Request a Quote

Tech Specs

TECHNICAL SPECIFICATIONS

12,000 LB Aluminum Lift Specifications

*Contact Basta Boatlifts for additional specifications

Lifting Capacity is the maximum weight the boat lift can lift. To calculate add total boat weight and all contents at time of lifting (fuel, gear, fresh water tank…)

Lift Capacity

12,000 LBS

Vertical Lift is measured at the aft end of the bunk rails from the fully lowered position to the fully raised position.

Vertical Lift

53″ or 65″

Visit the Basta Support page for instructions on how to calculate the required water depth to load your boat onto the lift. Contact Basta for additional methods to reduce minimum water depth.

Minimum Water Depth

23.45″

Frame Width

117″

Frame Length

167.25″

Solar Charger

Mono Crystalline

Remote Control Fobs

2

Cylinders

2

Standard Hose Length

27″

Submerged Hose Ends

Stainless

Connecting Hardware

Stainless

Manual

Manuals

Standard Features

  • Balanced Load H-Frame Featuring Over-Center Gravity Locking Position
  • Long-Life environmentally Friendly hydraulic fluid
  • Attractively-Styled Fiberglass dock box
  • 12-Watt Solar Panel
  • Two Wireless Remote Key Fobs
  • Reinforced Bunk Rails
  • Manual Control Switched in Power Box
  • Duplex-Bonded Synthetic Hydraulic Hoses
  • Stainless steel cylinder fittings and hose ends
  • Stainless Steel Hardware
